Product Description
This XPON ONT Dual Band AC1200 device combines GPON/EPON 1TEL compatibility, AC1200 XPON dual-band WiFi5, 4 Gigabit Ethernet ports, 1 telephone port, and CATV output, making it an ideal choice for FTTH triple-play services.With 4 external high-gain antennas, it delivers stable and wide-coverage wireless internet over both 2.4GHz and 5GHz. The integrated F-Type CATV RF port allows for analog TV signal transmission alongside internet and VoIP services.
Designed for residential, SOHO, and MDU environments, this unit supports GPON and EPON auto-detection, and works with most standard OLT platforms.
Key Features: Dual Band AC1200 XPON
-
XPON ONT EPON 1TEL (GPON & EPON auto-detect)
-
Dual-band 2.4GHz + 5GHz AC1200 WiFi5
-
4 × Gigabit Ethernet LAN ports
-
1 × RJ11 port for VoIP phone AC1200
-
1 × CATV RF output (F-type connector)
-
4 × 5dBi external antennas for extended coverage
-
Supports IGMP Snooping, QoS, VLAN, NAT
-
WPA2 wireless encryption
-
IPv4/IPv6 dual-stack support
-
Remote management via TR-069, OMCI
General Specifications: Dual Band AC1200 XPON
| Feature | Description |
|---|---|
| Device Type | XPON ONT (GPON/EPON Auto-adaptive) |
| Fiber Port | 1 × SC/APC (Single-mode, simplex) |
| LAN Ports | 4 × 10/100/1000 Mbps RJ45 |
| Telephone Port | 1 × RJ11 FXS (VoIP SIP/H.248 optional) |
| CATV Port | 1 × F-Type RF Output |
| Wireless Standard | IEEE 802.11ac/n/g/b/a (WiFi5) |
| WiFi Speed | AC1200 (2.4GHz up to 300 Mbps, 5GHz up to 867 Mbps) |
| Antennas | 4 × 5dBi External Antennas |
| XPON Mode | GPON & EPON (auto-sensing) |
| Management | Web UI, TR-069, OMCI |
Technical Specifications: Dual Band AC1200 XPON
| Parameter | 2.4GHz Band | 5GHz Band |
|---|---|---|
| Frequency Range | 2.400–2.4835 GHz | 5.150–5.825 GHz |
| Max Speed | Up to 300 Mbps | Up to 867 Mbps |
| MIMO Support | 2×2 | 2×2 |
| Modulation | BPSK to 256-QAM | BPSK to 256-QAM |
| Channel Bandwidth | 20/40 MHz | 20/40/80 MHz |
| Antenna Gain | 5dBi per antenna | 5dBi per antenna |
Electrical Characteristics: Dual Band AC1200 XPON
-
Power Supply: 12V DC / 1.5A
-
Power Consumption: < 15W
-
Integrated Lightning Protection: 4kV
-
CATV Working Voltage: 12–15V (active with power)
-
CATV Output: 47 – 870 MHz, Return Path: optional
Performance and Compliance
-
GPON: ITU-T G.984.2/3/4
-
EPON: IEEE 802.3ah
-
Full TR-069 remote configuration support
-
IGMP Snooping and Proxy for IPTV multicast
-
VoIP SIP/H.248 (if enabled)
-
VLAN, NAT, Port Forwarding, QoS support
-
IPv4/IPv6 Dual Stack
-
MAC Filtering, URL Filtering, DoS Protection
Environmental Specifications: Dual Band AC1200 XPON
| Parameter | Minimum | Maximum | Unit |
|---|---|---|---|
| Operating Temperature | 0 | 40 | °C |
| Storage Temperature | -40 | 70 | °C |
| Humidity (non-cond.) | 5 | 95 | % RH |
| Cooling System | Passive (fanless) |
Physical Characteristics
-
Dimensions: 220 × 135 × 35 mm
-
Weight: < 600 grams
-
Material: ABS flame-retardant plastic
-
Mounting: Desktop or wall-mountable
-
LED Indicators: Power, LOS, PON, LAN, WiFi, Phone, CATV
Certifications and Safety
-
CE – European Conformity
-
FCC – U.S. Compliance
-
RoHS – Restriction of Hazardous Substances
-
WiFi Certified – IEEE 802.11ac standard
-
CATV RF Output – IEC 60728 Compliant
-
IEC 60825-1 – Laser Safety Class 1
