Home Hot Sale FTTh Products SFP Optical Transceiver HUAWEI GPFD with 9db Compatible New SFP C++++ GPON Module
HW GPON OLT SFP C++++
HW GPON OLT SFP C++++ 8db 9db 10db Original New Module
Back to products
NEW GPHF OLT 9db Brand SFP C++++
NEW GPHF OLT 9db Brand SFP C++++ GPON Optical module

GPFD with 9db Compatible New SFP C++++ GPON Module

The NEW GPFD with 9dB SFP C++++ GPON OLT Module is a high-power, long-reach optical transceiver designed for GPON OLT slots, specifically for GPFD boards in fiber access networks. Offering a 9dB optical power budget and conforming to Class C++++, this SFP module supports stable transmission for up to 128 ONTs over 20 km of single-mode fiber.

Compare
Add to wishlist
Categories: HUAWEI, HUAWEI, HUAWEI, HUAWEI OLT, OLT, OLT, ONU/ONT, SFP Optical Transceiver Tags: #Fiber Optic Network, 1.25G upstream, 2.5G downstream, Enhanced GPON, FTTH, High-power SFP, ISP Equipment, Long distance SFP, Optical Line Terminal, pon network, RX sensitivity -32dBm, telecom, TX power 4~8dBm
Share:
  • Description
Description

Product Description

The NEW GPFD with 9dB SFP C++++ GPON OLT Module is a high-power, long-reach optical transceiver designed for GPON OLT slots, specifically for GPFD boards in fiber access networks. Offering a 9dB optical power budget and conforming to Class C++++, this SFP module supports stable transmission for up to 128 ONTs over 20 km of single-mode fiber.

Fully compliant with ITU-T G.984.2 and G.984.5, this transceiver operates at 2.488 Gbps downstream and 1.244 Gbps upstream using SC/UPC optical interfaces. It is hot-pluggable and supports real-time digital diagnostics (DDM/DOM), making it a reliable solution for high-density GPON deployments.


Key Features

  • 9dB optical power budget (C++++ class)

  • Compatible with Huawei GPFD service boards

  • 2.488 Gbps downlink / 1.244 Gbps uplink speeds

  • Complies with ITU-T G.984.x GPON standards

  • SC/UPC optical connector, single-mode fiber (SMF)

  • Extended range: up to 20 km

  • Hot-pluggable SFP form factor

  • Built-in DDM (Digital Diagnostics Monitoring)

  • Eye safety compliant (Class 1 laser)


General Specifications

Specification Description
Product Type GPON OLT SFP Optical Transceiver
Power Class C++++
Optical Power Budget 9dB
Compatibility Huawei GPFD OLT boards
Form Factor SFP (Hot-pluggable)
Transmission Distance Up to 20 km (SMF)
Connector Type SC/UPC
Fiber Type Single-mode fiber (G.652)
Operating Wavelengths TX: 1490 nm / RX: 1310 nm
Application FTTH / FTTx / GPON access networks
Digital Diagnostics Supported (DDM/DOM)

Technical Specifications

Parameter Min Typical Max Unit
Downstream Data Rate – 2.488 – Gbps
Upstream Data Rate – 1.244 – Gbps
TX Optical Power +3.0 +5.5 +6.5 dBm
RX Sensitivity –30 –28 –27 dBm
RX Overload – – –8 dBm
Bit Error Rate (BER) – – 10⁻¹² –
TX Wavelength 1490 – – nm
RX Wavelength 1310 – – nm
Insertion Loss – – < 0.5 dB
Return Loss 12 – – dB

Electrical Characteristics: GPFD

  • Supply Voltage: 3.3V ±10%

  • Power Consumption: < 2W

  • Differential Input Impedance: 100 Ω

  • Logic Interface: LVTTL / LVPECL

  • Power-on Initialization: < 300 ms

  • Hot-pluggable: Supported


Performance and Compliance: GPFD

  • ITU-T G.984.2 (Physical Layer) compliant

  • ITU-T G.984.5 (Reach Extension) compliant

  • SFP MSA compliant

  • Class C++++ optical performance

  • FCC, CE, RoHS compliant

  • IEC 60825-1 Class 1 laser safety

  • Supports DDM (temperature, voltage, TX/RX power)


Environmental Specifications: GPFD

Parameter Min Max Unit
Operating Temperature 0 +70 °C
Storage Temperature -40 +85 °C
Humidity (non-cond.) 5 95 %RH
MTBF 1,000,000 – Hours

Physical Characteristics:GPFD

  • Dimensions: 56 mm × 13.4 mm × 8.5 mm

  • Weight: < 30 grams

  • Housing: Metal with EMI shielding

  • Connector Interface: SC/UPC

  • Plug/Unplug Life: >500 cycles


Certifications & Safety:GPFD

  • CE – EU compliance

  • FCC – Electromagnetic compatibility

  • RoHS – Hazardous substance restriction

  • IEC 60825-1 – Class 1 laser safety

  • UL – Available on request
