- Model Number:Huawei HG8245H5
- Type:ONU
- Place of Origin:Zhejiang, China, Hangzhou,China
- Brand Name:Huawei
- Use:FTTX
- Warranty Time:1 year
- Network:Wireless Lan, wifi, 4g
- Product name:GPON ONU
- Brand:HUAWEI
- Model:HG8245H5
- Color:White
- Package:Box
- Warranty:1year
- Ports:1GE+3FE+1POTS+1USB+ wifi
- Package WITH:1Pcs/Box, with Power Plug
- Compatible:Transition Networks
-
- Supply Ability
- 10000 Piece/Pieces per Month
-
- Packaging Details
box
-
- Port
Hangzhou
- Picture Example:
- Lead time:Quantity(pieces)1 – 1>1Lead time (days)7To be negotiated
Product Description
The EchoLife HG8245H5 is a home gateway in Huawei Gigaband fiber solutions. The HG8245H5 provides 2 pots, 4 GE/FE auto-negotiation Ethernet ports, and a Wi-Fi port (standards compliance: 802.11b/g/n). It supports plug-and-play, remote diagnosis, and energy conservation features. The HG8245H5 provides ultra-bandwidth access using GPON technologies for home users. The high-performance forwarding capability of the device guarantees the voice, data, and HD video experience, which makes the device future-proof andan ideal terminal for FTTH deployment.
Product details
Application
Specification
|
Model Number
|
HG8245h5
|
|
LAN
|
4GE
|
|
Telephone
|
2pots
|
|
Wifi
|
2.4g
|
|
PPPOE
|
yes
|
|
Firmware
|
English
|
|
Dimension/pcs
|
250*185*35mm/0.44kgs
|
|
Out Port Contains
|
4GE+2TEL+USB+WiFi
|
|
Wavelength
|
Tx 1310nm, Rx 1490nm
|
|
Fiber Interface
|
SC/FC-UPC/APC Dual mode/Singal mode
|
|
RX sensitivity
|
>-28dBm(1490nm)
|
|
Machine Power
|
12V 1.0A
|
|
Working temperature
|
0°C~+40°C
|
