- Model Number:fiberhome hg6143d
- Type:ONU ONT
- Place of Origin:Guangdong, China
- Brand Name:fiberhome hg6143d
- Use:FTTH Solutions
- Warranty Time:1 Year
- Network:Wireless Lan
- Model:fiberhome hg6143d
- Dimensions:36.8*204*149MM
- Weight:120g
- Operating Temperature:0°C to +40°C
- Operating Humidity:5% RH to 95% RH (non-condensing)
- Power Adapter Input:100 V to 240 V AC, 50 Hz/60 Hz
- System Power Supply:11 V to 14 V DC, 1.5 A
- Configuration:1POTS + 4GE + Wi-Fi+ 2USB
- Selling Units:Single item
- Single package size: 15X13X7 cm
- Single gross weight:1.000 kg
- Package Type:CARTON BOX PACKING
- Lead time:Quantity(pieces)1 – 2000>2000Lead time (days)15To be negotiated
Brand New Low Price Fiberhome GPON ONU Fiberhome hg6143d 2.4g/5g dual wifi 4ge 1tel
Fiberhome HG6143D FTTH is an FTTH-type GPON optical network terminal. It provides users with communication and entertainment services in the form of data, voice, video and so on, to meet the integrated access demand of families and small-scaled enterprise. This model supports configuring the user-defined upgrade policies through the network management system so that the equipment can be upgraded automatically after being powered on and also collecting performance data of the ONT remotely via the network management system to enable real-time monitoring of the network performance.
Products Description
Application
|
FTTH FTTB FTTX Network
|
Ports
|
1GE+3FE+4LANS+1TEL+2USB
|
Antenna
|
Dual External Wifi Antennas
|
Firmware
|
English
|
Power Supply
|
EU, US, UK, AU etc
|
Average power consumption
|
8W
|
Operating environment
|
Temperature:-5℃~+40℃
|
Ambient Humidity
|
~90%
|
![](http://s.alicdn.com/@sc04/kf/H6a468cc969384dd7880fff92d20ee7162/243833273/H6a468cc969384dd7880fff92d20ee7162.jpg?quality=close)
![](http://s.alicdn.com/@sc04/kf/Hef678f10131841ada03d669d2c175a51y/243833273/Hef678f10131841ada03d669d2c175a51y.jpg?quality=close)
![](http://s.alicdn.com/@sc04/kf/Hb28e8deb3666448abf598f400f01c90bI/243833273/Hb28e8deb3666448abf598f400f01c90bI.jpg?quality=close)
![](http://s.alicdn.com/@sc04/kf/H7901a480880740d487eb2d3b3b1b5defl/243833273/H7901a480880740d487eb2d3b3b1b5defl.jpg?quality=close)
![](http://s.alicdn.com/@sc04/kf/H5aeed360556047ffba4bc6ba646b1784O/243833273/H5aeed360556047ffba4bc6ba646b1784O.jpg?quality=close)
![](http://s.alicdn.com/@sc04/kf/Ha6f09756a4174de2afe98a854720f74cs/243833273/Ha6f09756a4174de2afe98a854720f74cs.jpg?quality=close)
Product Paramenters
Features:
* GPON Access Capability
Conform to ITU-T G.984 series of standards, with good interoperability.
Provide large-capacity GPON transmission bandwidth: supports the downlink rate up to 2.5 Gbit/s and the uplink rate up to 1.25Gbit/s.
Support the dynamic bandwidth allocation (DBA) algorithm.
Support long-haul transmission. The maximum transmission distance can reach 20 km.
* Abundant Service Types
Provide abundant physical interfaces on the subscriber side to access multiple services such as Internet access, video, voice and home storage services.
* Wi-Fi Wireless Access
Provide Wi-Fi wireless access based on IEEE 802.11 a/b/g/n/ac to help you set up a safe and reliable wireless network.
Compatible with IEEE 802.11 a/b/g/n/ac and authenticated by Wi-Fi Alliance, with good compatibility with other WLAN devices.
Supports eight SSIDs (four for the 2.4 GHz band and another four for the 5 GHz band) so that users can set different wireless
networks as needed.
Supports multiple authentication and encryption modes to provide users with safe and reliable wireless access approaches.
* Network Storage and File Sharing
Provide a USB interface for connection with the USB interface storage device to provide convenient network storage and file sharing service.
Support plug-and-play and hot insertion of the USB interface
Conform to ITU-T G.984 series of standards, with good interoperability.
Provide large-capacity GPON transmission bandwidth: supports the downlink rate up to 2.5 Gbit/s and the uplink rate up to 1.25Gbit/s.
Support the dynamic bandwidth allocation (DBA) algorithm.
Support long-haul transmission. The maximum transmission distance can reach 20 km.
* Abundant Service Types
Provide abundant physical interfaces on the subscriber side to access multiple services such as Internet access, video, voice and home storage services.
* Wi-Fi Wireless Access
Provide Wi-Fi wireless access based on IEEE 802.11 a/b/g/n/ac to help you set up a safe and reliable wireless network.
Compatible with IEEE 802.11 a/b/g/n/ac and authenticated by Wi-Fi Alliance, with good compatibility with other WLAN devices.
Supports eight SSIDs (four for the 2.4 GHz band and another four for the 5 GHz band) so that users can set different wireless
networks as needed.
Supports multiple authentication and encryption modes to provide users with safe and reliable wireless access approaches.
* Network Storage and File Sharing
Provide a USB interface for connection with the USB interface storage device to provide convenient network storage and file sharing service.
Support plug-and-play and hot insertion of the USB interface
Application
Typical Solution:FTTH(Fiber To The Home)
Typical Business:INTERNET、IPTV、WIFI 、VOIP etc
![](http://s.alicdn.com/@sc04/kf/H7cb0d5b23d614bd19ba20f6ba5fcfa795/243833273/H7cb0d5b23d614bd19ba20f6ba5fcfa795.png?quality=close)
