- Model Number:zte f668 f673
- Type:ONU ONT
- Place of Origin:Guangdong, China
- Brand Name:zte f668 f673
- Use:FTTH Solutions
- Warranty Time:1 Year
- Network:Wireless Lan, POE, wifi
- Model:zte f668 f673
- Dimensions:220 mm x 34 mm x 187 mm
- Weight:700g (Include Package)
- Operating Temperature:0°C to +40°C
- Operating Humidity:5% RH to 95% RH (non-condensing)
- Power Adapter Input:100 V to 240 V AC, 50 Hz/60 Hz
- System Power Supply:11 V to 14 V DC, 1.5 A
- Configuration:f668c GPON 2.4g/5g Dual wifi 4GE + CATV
- Selling Units:Single item
- Single package size: 15X13X7 cm
- Single gross weight:1.000 kg
- Package Type:CARTON BOX PACKING
- Picture Example:
- Lead time:Quantity(pieces)1 – 2000>2000Lead time (days)15To be negotiated
Factory Direct Sale Low Price zte f668 FTTH f668c GPON 2.4g/5g Dual wifi 4GE + CATV
ZTE ZXHN F668 FTTH is a GPON Optical Network Terminal designed for FTTH scenario. This model offers 4 Ge Port 2 Voice Port WiFi CATV and 1 USB Port. The F668 features high-performance forwarding capabilities to ensure excellent experience with VoIP, Internet and HD video services
|
Model
|
ZTE ONT F668 F668C
|
|
Dimensions (H x W x D)
|
220 mm x 34 mm x 187 mm
|
|
Weight
|
700g (Include Package)
|
|
Operating Temperature
|
0°C to 40°C
|
|
Operating Humidity
|
5% RH to 95% RH (non-condensing)
|
|
Power Adapter Input
|
100 V to 240 V AC, 50 Hz/60 Hz
|
|
System Power Supply
|
11 V to 14 V DC, 0.5 A
|
|
Ports
|
GPON 2.4g/5g Dual wifi 4GE + CATV
|
|
Optical Connector
|
SC / UPC
|
|
Indicators
|
Power/PON/LOS/ALARM/LAN
|
|
GPON Interface
|
1x, SC/APC, 2,448 Gbit/s downstream 1,244 Gbit/s upstream
|
|
Other Interfaces
|
4x 10/100/1000 Base-T, 2x POTS, WiFi (2,4 GHz, 802.11b/g/n, 2×2 MIMO, WPA/WPA2,WPS), USB (2.0, File Sharing, DLNA), CATV
|
|
Operation Modes
|
Bridge, Router, AP
|
|
Wavelength for downstream
|
1480 nm – 1500 nm
|
|
Wavelength for upstream
|
1290 nm – 1330 nm
|
|
Sensitivity
|
7 W
|
|
GPON features
|
8x T-CONT, 32 GEM portů
|
|
Support
|
VLAN (802.1Q, 802.1P, 802.1ad), Multicast, QoS, DHCP Server/Client, NAT, IPv6 Dual Stack
|
|
Management
|
Local (WEB), OMCI, TR069
|
Products Description
Product Paramenters
Product Feature:
ZTE F668 FTTH is a GPON Optical Network Terminal designed for FTTH scenario. It provides subscribers rich, colourful, individualized, convenient and comfortable triple-play services including voice, video (IPTV/CATV) and high-speed internet access. it supports desktop mounting, wall mounting and network cabinet mounting. The ZXHN F668 complies with the ITU-T G.984 standard, provides 2.488 Gbps downlink and 1.244 Gbps uplink at the network side, and provides four GE ports, two POTS ports, one 802.11b/g/n(2*2 @2.4G Hz) Wi-Fi interface, one USB interface, and one RF interface at the user side. Home users can easily access voice services, video services, CATV service and many other kinds of high-speed broadband services by the ZXHN F668’s rich interfaces.
Rich Interfaces at Users Side:
It Provides four GE ports, two POTS ports, one 802.11b/g/n(2*2 @2.4G Hz) Wi-Fi interface, one USB interface, and one RF interface at user side to meet the needs of multiple terminal equipment access 。Users can access the PC, IPTV STB, Tablet PC, SmartPhone, phone, fax and other terminal equipment based on personal preferences, to fully enjoy all kinds of Internet services.
High Reliability:
The full-service access capability featuring high bandwidth, high performance, high reliability, and easy operation,
administration and maintenance (OAM) meets the continuously changing requirements of the customer, protects the legacy investment, and enhances the value of the operator’s network.
The full-service access capability featuring high bandwidth, high performance, high reliability, and easy operation,
administration and maintenance (OAM) meets the continuously changing requirements of the customer, protects the legacy investment, and enhances the value of the operator’s network.
Rich Interfaces at Users Side:
It Provides four GE ports, two POTS ports, one 802.11b/g/n(2*2 @2.4G Hz) Wi-Fi interface, one USB interface, and one RF interface at user side to meet the needs of multiple terminal equipment access 。Users can access the PC, IPTV STB, Tablet PC, SmartPhone, phone, fax and other terminal equipment based on personal preferences, to fully enjoy all kinds of Internet services.
Convenient and Secure Wi-Fi Access :
Users can build a convenient and secure wireless LAN, and access the Internet flexibly and reliably. Complies with the IEEE802.11b/g/n(2*2 @2.4GHz) standard, provides high-speed Wi-Fi access function 。Supports shared key authentication, WEP authentication, WPA-PSK, WPA2-PSK, and both mixed-mode security authentication, and ensure safe and reliable home Wi-Fi access .
Application
Typical Solution：FTTH(Fiber To The Home)
Typical Business：INTERNET、IPTV、WIFI 、VOIP etc
