- Model Number:GPON /EPON ONU
- Type:GPON ONU ONT
- Place of Origin:Guangdong, China
- Brand Name:GPON ONU
- Use:FTTH
- Model:CATV ONU
- Dimensions (H x W x D):152 x 105 x 30 mm
- Weight:0.27KG
- Operating Temperature:0°C to +40°C
- Operating Humidity:5% RH to 95% RH (non-condensing)
- Power Adapter Input:100 V to 240 V AC, 50 Hz/60 Hz
- System Power Supply:11 V to 14 V DC, 1.5 A
- Optical Connector:SC/APC SC/UPC
- Indicators:Power/PON/LOS/LAN/TEL/WLAN/WPS
- Ports:4GE+1TEL+1USB
-
- Supply Ability
- 5000 Piece/Pieces per Week
-
- Packaging Details
HK729 HK730 HK732 network wifi onu onu xpon catv 2.4g Compatible ZTE Network Unit 1GE+3FE+WIFI+CATV XPON ONU
-
- Port
shenzhen
- Lead time:Quantity(pieces)1 – 2000>2000Lead time (days)5To be negotiated
FTTH GPON EPON ONU
Brief Introduction :
HK730 is the terminal equipment of a series of XPON which complies fully with ITU-G.984.1/2/3/4 standard and meet the
energy-saving of G.987.3 protocol. It is based on mature and stable and high cost-effective XPON technology which adopts
high-performance XPON Realtek chipset and has high reliability, easy management, flexible configuration, robustness, good quality
service guarantee(Qos). HK730 adopts MTK MT7603EN scheme for WIFI application that supports IEEE802.11b/g/n standard. It also
provides the WEB management page and simplifies the configuration of WIFI. HK730 supports 1 RF port for CATV, which can be
switched off on OLT terminal. HK730 has the automatic function of EPON and GPON, which is realized by the Pure software.
Auto-negotiation(When the onu works, it will automatically identify EPON and GPON mode according to the access optical signal,
otherwise it automatically defaults to GPON mode)
|
Parameters
|
HK ONU English Firmware
|
|
Dimensions (H x W x D)
|
200×136 x 30mm
|
|
Weight
|
255g / 420g (Include Package)
|
|
Operating Temperature
|
0°C to +40°C
|
|
Firmware Language
|
English
|
|
Power Adapter Input
|
100 V to 240 V AC, 50 Hz/60 Hz
|
|
System Power Supply
|
11 V to 14 V DC, 1.5 A
|
|
Static Power Consumption
|
3.1W
|
|
Maximum Power Consumption
|
7.5W
|
|
Ports
|
1GE+3FE +WIFI+USB+TEL+CATV
|
|
Optical Connector
|
SC/UPC SC/APC
|
|
Indicators
|
Power/PON/LOS/LAN/TEL/WLAN/WPS
|
