Product Description
New original router hg8245h gpon firmware 4GE+2TEL+WIFI 5dbi
The EchoLife HG8245H5 is a routing-type ONT in the all-optical access solution. It uses the GPON technology to implement ultra-broadband access for users. It provides 4 GE+2 POTS+1 USB+1 WiFi(4 GE ports, 2 POTS ports, 1 USB port and 1 2.4G WiFi port). The high forwarding performance ensures the user experience of voice, data and HD video services, and provides customers with an ideal all-optical access solution and future-oriented service support capability.
![](http://s.alicdn.com/@sc01/kf/H2c5cf656db334fbd84fb516cca59861aN/243367120/H2c5cf656db334fbd84fb516cca59861aN.jpg?quality=close)
![](http://sc01.alicdn.com/kf/H2c5cf656db334fbd84fb516cca59861aN/243367120/H2c5cf656db334fbd84fb516cca59861aN.jpg)
![](http://s.alicdn.com/@sc01/kf/Hf9b43e651734457ea96dda2dc4d04627X/243367120/Hf9b43e651734457ea96dda2dc4d04627X.jpg?quality=close)
![](http://sc01.alicdn.com/kf/Hf9b43e651734457ea96dda2dc4d04627X/243367120/Hf9b43e651734457ea96dda2dc4d04627X.jpg)
![](http://s.alicdn.com/@sc01/kf/H2c5cf656db334fbd84fb516cca59861aN/243367120/H2c5cf656db334fbd84fb516cca59861aN.jpg?quality=close)
![](http://sc01.alicdn.com/kf/H2c5cf656db334fbd84fb516cca59861aN/243367120/H2c5cf656db334fbd84fb516cca59861aN.jpg)
![](http://s.alicdn.com/@sc02/kf/H717c74c7315c4173a463eb69fb1cda538/243367120/H717c74c7315c4173a463eb69fb1cda538.jpg?quality=close)
![](http://sc02.alicdn.com/kf/H717c74c7315c4173a463eb69fb1cda538/243367120/H717c74c7315c4173a463eb69fb1cda538.jpg)
![](http://s.alicdn.com/@sc01/kf/Hd726582da5b04854b74187e755d65450A/243367120/Hd726582da5b04854b74187e755d65450A.jpg?quality=close)
![](http://sc01.alicdn.com/kf/Hd726582da5b04854b74187e755d65450A/243367120/Hd726582da5b04854b74187e755d65450A.jpg)
![](http://s.alicdn.com/@sc01/kf/H76e167ee30534dd299e77065d928ada4P/243367120/H76e167ee30534dd299e77065d928ada4P.jpg?quality=close)
![](http://sc01.alicdn.com/kf/H76e167ee30534dd299e77065d928ada4P/243367120/H76e167ee30534dd299e77065d928ada4P.jpg)
![](http://s.alicdn.com/@sc02/kf/H32041e2151744d018057eec9c0d6cf25r/243367120/H32041e2151744d018057eec9c0d6cf25r.png?quality=close)
![](http://sc02.alicdn.com/kf/H32041e2151744d018057eec9c0d6cf25r/243367120/H32041e2151744d018057eec9c0d6cf25r.png)
Application and Advantage:
1.Full compatible with ITU-T G.984.
2.Support port-based rate limitation and bandwidth control
3.Integrated OMCI remote configuration and maintenance function.
4.Support data enscryption, group broadcasting, port Vlan separation ,RSTP,etc.
5.Support Dynamic Bandwidth Allocation (DBA)
6.Support ONT auto-discovery/Link detection/remote upgrade of software;
7.Support VLAN division and user separation to avoid broadcast storm;
8.Support power-off alarm function ,easy for link problem detection
9.Support broadcasting storm resistance function
10.Support port isolation between different ports
11.Support ACL and SNMP to configure data packet filter flexibly
12.Specialized design for system breakdown prevention to maintain stable system
13.Support software online upgrading
14.EMS network management based on SNMP ,convenient for maintenance
2.Support port-based rate limitation and bandwidth control
3.Integrated OMCI remote configuration and maintenance function.
4.Support data enscryption, group broadcasting, port Vlan separation ,RSTP,etc.
5.Support Dynamic Bandwidth Allocation (DBA)
6.Support ONT auto-discovery/Link detection/remote upgrade of software;
7.Support VLAN division and user separation to avoid broadcast storm;
8.Support power-off alarm function ,easy for link problem detection
9.Support broadcasting storm resistance function
10.Support port isolation between different ports
11.Support ACL and SNMP to configure data packet filter flexibly
12.Specialized design for system breakdown prevention to maintain stable system
13.Support software online upgrading
14.EMS network management based on SNMP ,convenient for maintenance
![](http://s.alicdn.com/@sc01/kf/H32e07ea8b8334a498e68aab707f5e81aJ/243367120/H32e07ea8b8334a498e68aab707f5e81aJ.jpg?quality=close)
![](http://sc01.alicdn.com/kf/H32e07ea8b8334a498e68aab707f5e81aJ/243367120/H32e07ea8b8334a498e68aab707f5e81aJ.jpg)
Specification
Model
|
EchoLife HG8245H5
|
Type
|
Routing
|
Dimensions (H x W x D)
|
168 mm x 115 mm x 30 mm (without antenna and pads)
|
Operating Temperature
|
0°C to 40°C
|
Operating Humidity
|
5% RH to 95% RH (non-condensing)
|
Power Adapter Input
|
100V to 240V AC, 50 Hz/60 Hz
|
System Power Supply
|
11V to 14V DC, 0.5A
|
Network-side Ports
|
GPON
|
User-side Ports
|
2 POTS + 4 GE + 2.4G Wi-Fi + 1 USB
|
Indicators
|
POWER, PON, LOS, LAN1, LAN2, LAN3, LAN4, TEL, USB, WLAN, and WPS
|
