Product Description
This series of 12V2A 12V3A EU power adapter is designed for consistent and reliable power delivery to a wide range of electronics. Available in multiple output options (1A, 1.5A, 2A, 3A), these are used in high-efficiency switching technology, making them compact and energy-efficient.
Fitted with a European two-pin (EU) plug, they are ideal for powering routers, LED lights, security cameras, ONUs, and other 12V-compatible equipment. It feature overvoltage, overcurrent, and short-circuit protection, and comply with CE, RoHS, and EMC standards.
Key Features
-
Regulated 12V DC output
-
Output options: 1A, 1.5A, 2A, 3A
-
Universal AC input (100–240V, 50/60Hz)
-
EU two-pin plug for European use
-
Standard 5.5mm × 2.1mm DC connector
-
High conversion efficiency
-
Lightweight and compact plastic case
-
Built-in protection (OVP, OCP, SCP)
-
RoHS and CE certified
-
Suitable for routers, LED strips, cameras, and more
General Specifications: Power Adapter
| Feature | Specification |
|---|---|
| Input Voltage | 100 – 240V AC |
| Input Frequency | 50 / 60 Hz |
| Output Voltage | 12V DC (regulated) |
| Output Current Options | 1A / 1.5A / 2A / 3A |
| Output Power Range | 12W – 36W |
| DC Plug Type | 5.5mm (outer) × 2.1mm (inner) barrel |
| Efficiency | >85% typical |
| Plug Type | EU two-pin (Type C) |
| Cable Length | 1 – 1.2 meters |
| Ripple & Noise | <120 mVp-p |
Technical Models Comparison: Power Adapter
| Model | Output Current | Max Output Power | Suggested Use |
|---|---|---|---|
| 12V 1A | 1.0A | 12W | LED strips, ONUs, routers |
| 12V 1.5A | 1.5A | 18W | IP cameras, IoT devices |
| 12V 2A | 2.0A | 24W | WiFi routers, ONTs, fans |
| 12V 3A | 3.0A | 36W | CCTV DVRs, smart boxes |
Electrical Characteristics: 12V2A 12V3A Power Adapter
-
Load Regulation: ±5%
-
Line Regulation: ±1%
-
Output Accuracy: ±0.5V
-
Protection Functions:
-
Over Voltage Protection (OVP)
-
Over Current Protection (OCP)
-
Short Circuit Protection (SCP)
-
Environmental Specifications: Power Adapter
| Parameter | Minimum | Maximum | Unit |
|---|---|---|---|
| Operating Temperature | 0 | 45 | °C |
| Storage Temperature | -20 | 80 | °C |
| Humidity | 5 | 90 | % RH |
| Cooling Method | Passive (fanless) | – |
Physical Characteristics: Power Adapter
-
Housing Material: Flame-retardant ABS
-
Adapter Color: Black (standard)
-
Dimensions (approx.): 70 × 35 × 25 mm
-
Weight: 100 – 160 grams (depending on model)
-
Cable Type: Flexible PVC insulated
Certifications and Safety: Power Adapter
-
CE certified (EU safety and EMC compliance)
-
RoHS compliant (free from hazardous materials)
-
Overload, overvoltage, and short circuit protected
-
High insulation resistance and surge resistance
-
EN 55032 / EN 55024 compliant
