SC/UPC 1×8 Blockless High Quality Type 250um Fiber Splitter
The SC/UPC 1×8 Blockless Fiber Splitter is a premium-grade passive optical component used for precise and stable signal distribution in modern FTTH, FTTx, and PON networks. This PLC (Planar Lightwave Circuit) splitter evenly divides one optical input signal into eight outputs with low insertion loss, excellent uniformity, and broadband operation, ensuring dependable performance across your network.
The blockless 250um bare fiber design makes this splitter ultra-compact and easy to splice directly into fiber trays, closures, or wall-mounted boxes — a perfect choice for installers who need flexibility and space-saving deployment.
Key Features
-
Splitter Type: 1×8 PLC Splitter
-
Design: Blockless type with 250um bare fiber, lightweight and compact
-
Connector Type: SC/UPC connectors on input and output fibers
-
Operating Wavelength: 1260~1650nm wideband PON compatibility
-
Low Insertion Loss: Stable and uniform optical signal splitting
-
High Quality: Fully compliant with Telcordia GR-1209 and GR-1221 standards
-
Easy Installation: Designed for quick integration in splice trays and fiber management systems
-
Condition: 100% Brand New, factory-tested and certified
Technical Specifications
| Category | Specification |
|---|---|
| Splitter Type | PLC (Planar Lightwave Circuit) |
| Configuration | 1×8 |
| Fiber Type | Singlemode, 250um bare fiber |
| Connector Type | SC/UPC |
| Operating Wavelength | 1260–1650nm |
| Insertion Loss | ≤ 10.5 dB |
| Uniformity | ≤ 0.8 dB |
| Return Loss | ≥ 55 dB |
| Polarization Dependent Loss (PDL) | ≤ 0.2 dB |
| Directivity | ≥ 55 dB |
| Operating Temperature | -40°C to +85°C |
| Compliance | Telcordia GR-1209, GR-1221, RoHS |
SC/UPC 1×8 Blockless Application
FTTH/FTTx Networks: PON signal splitting to multiple subscribers
Passive Optical LANs: Reliable signal distribution in enterprise networks
CATV Networks: Efficient RF over fiber signal management
Test Systems & Labs: Handy for optical testing and measurement setups
Space-Constrained Installs: Blockless design fits tight enclosures, splice trays, and distribution boxes
Customization & OEM Services
Custom Fiber Lengths: Tailored input/output pigtail lengths available
Connector Options: SC/APC, LC/UPC, LC/APC, FC/UPC on request
OEM Branding: Private label & custom packaging for resellers & system integrators
Project Kits: Ready-to-install splitter bundles for large rollouts
Full Test Reports: Insertion loss and uniformity data included with each unit
SC/UPC 1×8 Blockless Wholesale & Bulk Supply
Competitive Factory Pricing: Attractive discounts for large quantities
Global Shipping: Export-ready packaging with fast worldwide delivery
Dedicated Support: Personal account managers for your projects
Full Warranty: 100% genuine, brand new, and covered under manufacturer warranty
SC/UPC 1×8 Blockless Why Choose Us
High-Quality Fiber Components — Fully Tested & Certified
Flexible Customization & OEM Services
Best Wholesale Rates — Ideal for ISPs, VARs, and project integrators
Secure Export Logistics & Reliable Supply Chain
Expert Technical Support — From Planning to Deployment
Contact Us for Best Pricing
Upgrade your fiber network with the SC/UPC 1×8 Blockless High Quality Type 250um Fiber Splitter — a trusted solution for stable, efficient, and cost-effective optical signal distribution.
