CR8DE1KB00F0 Huawei Description:
The CR8DE1KB00F0 Huawei is a brand new, original Huawei Line Processing Unit (LPU) developed for the Huawei NetEngine 8000 series routers, which deliver industry-leading performance and carrier-grade reliability for next-generation IP backbone and metro networks.
This LPU enables high-speed packet forwarding, multi-service processing, and advanced routing features that make it ideal for large-scale network deployments. Supporting high-density interfaces and modern technologies like SRv6, advanced QoS, and flexible network slicing, the CR8DE1KB00F0 helps operators and enterprises achieve scalable, resilient, and intelligent network operations.
Key Features:
-
Model: CR8DE1KB00F0
-
Condition: 100% Brand New, Original Huawei
-
Type: NetEngine Line Processing Unit
-
Application: High-performance routing and forwarding in backbone and metro networks
-
Interface Support: Compatible with high-density 100G/400G connections for ultra-broadband transport
-
High Reliability: Supports hot-swappable installation and redundancy design for always-on networks
-
Intelligent Capabilities: Supports Segment Routing (SRv6), hierarchical QoS, and advanced O&M
-
Energy Efficient: Low power consumption and smart design for green network operations
-
Compatibility: Fully compatible with Huawei NetEngine 8000 series chassis and ecosystem
Tech Specs:
Specifications
| Item | Details |
|---|---|
| Basic Function | Provides one 400GE QSFP-DD interface and one QSFP28 optical amplifier interface on the line side. 1. QSFP-DD interface rate: 400 Gbit/s 2. QSFP28 fiber amplifier interface supports fiber amplifier modules. |
| Reliability and Availability | Hot swappable |
| Restrictions and Remarks | When ZR optical modules are used, short-term operating temperature must be reduced to 50°C. For ZR+ optical modules, both long-term and short-term operating temperatures must be reduced to 40°C. |
| Breakout Supported | Not supported in V800R023C00 |
| Interface Rate Auto-Sensing Supported | Not supported |
| FlexE Supported | Supported
– When used with the CR8D0SFUT6D0 SRU in slots 3–6, port 1 can be added to a FlexE group. port-id range: 1000–3000; maximum 56 FlexE clients. |
Physical Specifications
| Parameter | Value |
|---|---|
| Dimensions (H × W × D) | 190 mm × 590 mm × 470 mm |
| Weight | 5.7 kg |
| Typical Power Consumption | 75 W |
| Typical Heat Dissipation | 243.3 BTU/hour |
| Long-Term Operating Temperature | 0°C to 45°C (32°F to 113°F) |
| Short-Term Operating Temperature | –5°C to +55°C (23°F to 131°F) |
CR8DE1KB00F0 Huawei Applications:
The CR8DE1KB00F0 Line Processing Unit is perfectly suited for:
-
National and regional IP backbone networks
-
Metro core and aggregation layers
-
Large enterprise and campus core routing
-
Cloud interconnection and data center transport
-
5G transport networks and ultra-broadband deployments
-
ISP and telecom operator multi-service integration
