- Model Number:GPON /EPON ONU
- Type:GPON ONU ONT
- Place of Origin:Guangdong, China
- Brand Name:GPON ONU
- Use:FTTH
- Model:zte f660 v6
- Dimensions (H x W x D):152 x 105 x 30 mm
- Weight:0.27KG
- Operating Temperature:0°C to +40°C
- Operating Humidity:5% RH to 95% RH (non-condensing)
- Power Adapter Input:100 V to 240 V AC, 50 Hz/60 Hz
- System Power Supply:11 V to 14 V DC, 1.5 A
- Optical Connector:SC/APC SC/UPC
- Indicators:Power/PON/LOS/LAN/TEL/WLAN/WPS
- Ports:4GE+1TEL+1USB
-
- Supply Ability
- 5000 Piece/Pieces per Week
-
- Packaging Details
English Firmware Epon Optical Network Unit 1GE+3FE+WIFI+USB 4 LAN 2 POT 1USB WIFI GPON ONU ZTE ZXA10 F660 V6
-
- Port
shenzhen
- Lead time:Quantity(pieces)1 – 2000>2000Lead time (days)5To be negotiated
Products Description
FTTH GPON EPON ONU
English Firmware Epon Optical Network Unit 1GE+3FE+WIFI+USB 4 LAN 2 POT WIFI GPON ONU ZTE ZXA10 F660 V6
Brief Introduction :
ZTE ZXA10 F660 FTTH is a GPON Optical Network Terminal for HGU (Home Gateway Unit), and it supports L3 function to help
subscribers build an intelligent home network. ZTE ZXA10 F660 FTTH provides users with rich, colourful, individualized, and
comfortable triple-play services including voice, video (IPTV) and high-speed internet access. This model also supports IEEE
802.11b/g/n that allows the subscriber to enjoy the internet via wifi. It has a small, smart appearance and green, energy-saving
advantage.
comfortable triple-play services including voice, video (IPTV) and high-speed internet access. This model also supports IEEE
802.11b/g/n that allows the subscriber to enjoy the internet via wifi. It has a small, smart appearance and green, energy-saving
advantage.
Product Specification :
|
Parameters
|
ZXHN F660 V6.0
|
|
Dimensions (H x W x D)
|
180*125*40mm/0.25kg
|
|
Weight
|
0.25KG
|
|
Operating Temperature
|
0ºC to 45ºC
|
|
Firmware Language
|
English
|
|
Power Adapter Input
|
100 to 240 V AC, 50–60 Hz
|
|
System Power Supply
|
12 V DC, 1.5 A
|
|
Static Power Consumption
|
3.1W
|
|
Maximum Power Consumption
|
7.5W
|
|
Ports
|
(1GE+3FE)*LAN+ 2*POTS+ WIFI(inside)
|
|
Optical Connector
|
SC/UPC SC/APC
|
|
Indicators
|
Power/PON/LOS/LAN/TEL/WLAN/WPS
|
Product Overview :
Product Paramenters
Application
Typical Solution：FTTH(Fiber To The Home)Typical Business：INTERNET、IPTV、WIFI 、VOIP etc
