SKU 1600660388823 Category
  • Private Mold:Yes
  • Products Status:Stock
  • Ports:24
  • Transmission Rate:10/100Mbps
  • Function:LACP, POE, QoS, VLAN Support
  • Communication Mode:Half-Duplex
  • Switch Capacity:14.8Gbp
  • Place of Origin:Guangdong, China
  • Device Type:Switch
  • Input voltage:AC(100-240)V
  • Product status:Stock
  • IP Garde:IP30
  • PoE Ports:16 PoE Ports
  • Weight:2kg
  • Brand:ONV Switch
  • Dimensions (W x D x H):270*181*44.5mm
  • MOQ:1
  • Color:Balck
  • Selling Units:Single item
  • Single package size: 32X25X8 cm
  • Single gross weight:1.000 kg
  • Package Type:50pcs: 515*505*337mm
  • Lead time:Quantity(pieces)1 – 5051 – 100>100Lead time (days)1216To be negotiated

1024PL series is an unmanaged PoE switch independently developed by ONV.It has 24*10/100M PoE ports and 2*10/100/1000M uplink RJ45 ports . Port 1-24 can support IEEE 802.3af/at standard PoE power supply, and single port PoE power reaches 30W. The maximum PoE output power is 250W.

10/100Mbps access , gigabit uplink

     All series support “10/100M RJ45 port and 10/100/1000M RJ45 port”combination, which enables users to flexibly build networking to meet the needs of various scenarios.

  —   Support non-blocking wire-speed forwarding.

  —   Support full-duplex based on IEEE802.3x and half-duplex based on backpressure.

Intelligent PoE power supply

 —   24*10/100Base-TX RJ45 ports, meeting the needs of security monitoring, teleconferencing system, wireless coverage, and other scenarios.

 —    IEEE 802.3af/at PoE standard, without damaging non-PoE devices.

 —    Priority system for PoE port, it will supply power to the high priority level port first when the power budget is insufficient and avoid overwork of the device.

Innovative function

   Long distance switch: When opening, the speed of 17-24 port is reduced to 10M. With the existing          twisted pair cable, the transmission limit of the twisted pair can be broken. The transmission                  distance can reach 250 meters; on the other hand, It can solve the problem of poor transmission            caused by line aging.

Stable and reliable

  —   Low power consumption, IP30 metal casing, The fan active cooling design.

  —   Self-developed power supply, high redundancy design, providing a long term and stable PoE power output.

  —   CCC,CE, FCC, RoHS.

  —   Plug and play, no configuration, simple and convenient.

  —   Desktop and 1U/19 inch installation.

  —   The user-friendly panel, it can show the device status through the LED indicator of PWR, PoE.

Fixed Port
16*10/100Base-TX PoE ports


2*10/100/1000Base-T Uplink RJ45

ports (Data)
24*10/100Base-TX PoE ports


2*10/100/1000Base-T Uplink RJ45

 ports (Data)
Ethernet Port
10/100Base-T(X) ,10/100/1000Base-T automatic detection, full/half Duplex

MDI/MDI-X adaptive
Twisted Pair Transmission
10BASE-T: Cat3,4,5 UTP(≤100 meter)

100BASE-TX: Cat5 or later UTP(≤100 meter)

1000BASE-T: Cat5e or later UTP(≤100 meter)
Functional Switch
After opening, port 17-24 support

10M/250 meters long distance

After opening, port 17-24 support

10M/250 meters long distance

Note: When the switch status changes, the PoE switch must be restarted for the switch function to take effect.
Chip Parameter
Network Protocol
IEEE802.3 10BASE-T; IEEE802.3i 10Base-T;

IEEE802.3u 100Base-TX; IEEE802.3ab 1000Base-T;


Forwarding Mode
Store and Forward(Full Wire Speed)
Switching Capacity


Buffer Memory
LED Indicator
Power: PWR (green); Network: 1-16(24)/G1-2 (green); POE :PoE (green)
PoE & Power
PoE Port
Port 1 to Port 16 IEEE802.3af/at @ POE
Port 1 to Port 24 IEEE802.3af/at @ POE
Power Supply Pin
Default: 1/2 (+), 3/6 (-) ; Optional 4/5(+), 7/8(-)
Max Power Per Port
30W; IEEE802.3af/at
Total PWR / Input Voltage
250W (AC100-240V)
600W (AC100-240V)
Power Consumption
Standby:<15W;Full load:<240W
Standby:<20W;Full load:<250W
Power Supply
Built-in power supply, AC 100 ~ 240V 50-60Hz 4.1A,

support short circuit, over current, overload protection
Built-in power supply, AC 100~240V 50-60Hz 6.6A
Physical Parameter
Operation TEMP / Humidity
-20~+55°C;5%~90% RH Non condensing
Storage TEMP / Humidity
-40~+75°C;5%~95% RH Non condensing
Dimension (L*W*H)
Net /Gross Weight
<1.7kg / <2.2kg
<2.3kg / <3kg
Desktop, 19 inch 1U cabinet
Certification & Warranty
Lightning protection
Lightning protection: 4KV 8/20us; Protection level: IP30
CCC;CE mark, commercial; CE/LVD EN60950;FCC Part 15 Class B; RoHS;
1 years , lifelong maintenance.
