- Private Mold:Yes
- Products Status:Stock
- Ports:6
- Transmission Rate:10/100Mbps
- Function:LACP, POE, QoS, VLAN Support
- Communication Mode:Full-Duplex
- Switch Capacity:14.8Gbps
- Place of Origin:Guangdong, China
- Device Type:Switch
- Input voltage:AC(100-240)V
- Product status:Stock
- IP Garde:IP40
- PoE Ports:6*10/100Mbps PoE Ports
- Weight:1kg
- Dimensions (W x D x H):142.5*115*40mm
- MOQ:1
- Color:Balck
- Selling Units:Single item
- Single package size: 21X25X5 cm
- Single gross weight:1.000 kg
- Package Type:50pcs: 515*505*337mm
- Lead time:Quantity(pieces)1 – 5051 – 100>100Lead time (days)1216To be negotiated
10/100Mbps Access ,Dual RJ45 Ports Uplink
— 6*10/100Base-TX RJ45 ports ,which is more convenient for users to flexibly set up to meet the network requirements of various scenarios.
— Support non-blocking wire-speed forwarding.
— Support full-duplex based on IEEE802.3x and half-duplex based on backpressure.
Intelligent PoE Power Supply
— 4*10/100Base-TX RJ45 ports, meeting the needs of security monitoring, teleconferencing system, wireless coverage, and other scenarios.
— IEEE 802.3af/at PoE standard, without damaging non-PoE devices..
Innovative Function
— Long-distance file: When turned on, the rate of port 3-6 is reduced to 10M. Using the existing
twisted-pair cable, the limit of 100 meters of twisted-pair transmission can be exceeded, and the
transmission distance can reach up to 250 meters; on the other hand, Can solve the problem of poor transmission due to aging of the line.
— Video Surveillance Mode: Opens with long-distance switches. Ports 3-6 are isolated from each other
but communicate with ports 1-2 to prevent DHCP conflicts, optimize port cache utilization, and
reduce broadcast storms.
Stable and Reliable
— Low power consumption, galvanized steel casing, no fan.
— Self-developed power supply, high redundancy design, providing a long term and stable PoE power output.
— CCC,CE, FCC, RoHS.
— Plug and play, no configuration, simple and convenient.
— The user-friendly panel, it can show the device status through the LED indicator of PWR,Link,PoE.
|
Fixed Port
|
4*10/100Base-TX PoE ports (Data/Power)
2*10/100Base-TX Uplink RJ45 ports (Data)
|
|
|
Ethernet Port
|
Port 1-6 can support 10/100Base-TX automatic detection, full/half Duplex MDI/MDI-X adaptive
|
|
|
Twisted Pair Transmission
|
10BASE-T: Cat3,4,5 UTP(≤100 meter)
100BASE-TX: Cat5 or later UTP(≤100 meter) |
|
|
Functional Switch
|
1*(Extender+CCTV)
|
After opening, port 17-24 support
10M/250 meters long distance
transmission.
|
|
Note: When the switch status changes, the PoE switch must be restarted for the
switch function to take effect.
|
||
|
Chip Parameter
|
||
|
Network Protocol
|
IEEE802.3 10BASE-T; IEEE802.3i 10Base-T;
IEEE802.3u 100Base-TX; IEEE802.3x |
|
|
Forwarding Mode
|
Store and Forward(Full Wire Speed)
|
|
|
Switching Capacity
|
1.6Gbps
|
|
|
Forwarding
Rate@64byte |
0.89Mpps
|
6.55Mpps
|
|
Mac
|
1K
|
|
|
Buffer Memory
|
68K
|
|
|
LED Indicator
|
Power: PWR (green); Network: Link（yellow）; POE :PoE (green)
Functional switch : EXTEND (green)
|
|
|
PoE & Power
|
||
|
PoE Port
|
Port 3 to 6 IEEE802.3af/at @ POE
|
Port 1 to Port 24 IEEE802.3af/at @ POE
|
|
Power Supply Pin
|
Default: 1/2 (+), 3/6 (-) ; Optional 4/5(+), 7/8(-)
|
|
|
Max Power Per Port
|
30W; IEEE802.3af/at
|
|
|
Total PWR / Input Voltage
|
65W/ 52VDC
|
110W/52VDC
|
|
Power Supply
|
External power adaptor
AC100~240V 50-60Hz 1A
|
External power adaptor
AC100~240V 50-60Hz 2.2A
|
|
Power Consumption
|
Standby<4W, Full load<65W
|
Standby<5W, Full load<110W
|
|
Physical Parameter
|
||
|
Operation TEMP / Humidity
|
-20~+55°C;5%~90% RH Non condensing
|
|
|
Storage TEMP / Humidity
|
-40~+75°C;5%~95% RH Non condensing
|
|
|
Dimension (L*W*H)
|
118*89*28mm
|
330*204*44mm
|
|
Net /Gross Weight
|
<0.4kg / <0.9kg
|
<0.6kg / <1.2kg
|
|
Installation
|
Desktop, Wall-mounted
|
|
|
Certification & Warranty
|
||
|
Lightning protection
|
Lightning protection: 4KV 8/20us; Protection level: IP30
|
|
|
Certification
|
CCC;CE mark, commercial; CE/LVD EN60950;FCC Part 15 Class B; RoHS
|
|
|
Warranty
|
1 years, lifelong maintenance.
|
