- Private Mold:NO
- Products Status:Stock
- Ports:≤ 8
- Transmission Rate:10/100/1000Mbps
- Function:POE
- Communication Mode:Full-Duplex & Half-Duplex
- Switch Capacity:5.6G
- Brand Name:Accept OEM
- Model Number:HT-POE5624
- Place of Origin:Guangdong, China
- PoE Standard::IEEE 802.3af
- Address Database Size::1K
- PoE Port Power::15.4W for each POE port
- Warranty::12 Months
- 1000M::2 UPLINK port
- MTBF::190,000 hours (about 21 years)
- Forwarding Mode::Store-And-Forward
- Function::POE
- Brand Name::Accept OEM
- Package Type::Neutral gift box
- Selling Units:Single item
- Single package size: 28X23X7 cm
- Single gross weight:1.200 kg
- Package Type:Neutral gift box
- Lead time:Quantity(pieces)1 – 12 – 500501 – 1000>1000Lead time (days)32535To be negotiated
Product Description
|
Model
|
S5624-24G-2TS
|
|
1000M POE Rj45
|
24
|
|
1000M SFP UP
|
2
|
|
Exchange Mechanism
|
Store-and-forward
|
|
Bandwidth
|
56G
|
|
MAC
|
8K
|
|
Environmental
|
Working Temperature: -10℃～55℃
Storage temperature: -40℃～70℃ Working Humidity ：10%～90% RH non-condensing
Storage Humidity：5%～90% RH non-condensing |
|
Power input
|
AC 100-265V 50/60Hz 3.5A MAX300W
|
|
POE
|
IEEE802.3af/at, Port PoE MAX 30W，
|
|
Standards Protocols
|
IEEE 802.3
IEEE 802.3i 10BASE-T IEEE 802.3u 100BASE-TX IEEE 802.3ab 1000BASE-T IEEE 802.3z 1000BASE-X IEEE 802.3af/at IEEE 802.3x |
|
Speed
|
Ethernet 10Mbps half-duplex, 20Mbps full-duplex
Fast Ethernet 100Mbpshalf-duplex, 200Mbps full-duplex Gigabit Ethernet 2000Mbps full-duplex |
|
Network Media
|
10Base-T: Pair 2 Category 3(Cat3) and above UTP/STP(≤150m)
100Base-TX: Pair 2 Category 5(Cat5) and above UTP/STP(≤150m) 1000Base-T: Pair 4 Category 5(Cat5e) and above UTP/STP(≤150m) 1000Base-SX:62.5μm/50μm MMF(2m~550m) 1000Base-LX:62.5μm/50μm MM(2m~550m) or 10μm SMF(2m~5000m) |
|
Product
specifications |
Product Size：440mm*290mm*45mm（L*W*H）
package Size：497mm*393mm*97mm（L*W*H） Weight:5.8kg |
