Huawei MA5608T Chassis – Branded OLT Frame with 1× MCUD GE Main Control Board | Carrier-Grade Compact GPON Platform
Product Overview
The Huawei MA5608T chassis is a compact, carrier-grade GPON OLT platform designed for flexible and scalable fiber access networks. This configuration comes pre-installed with one MCUD GE Main Control Board, making it ready for integration with GPON service boards, uplink modules, and power units.
Ideal for FTTH, FTTB, and rural broadband deployments, the MA5608T supports a wide range of service boards and uplink types including GPON, XG-PON, 10GE, and Combo PON. The chassis is designed to deliver high availability, dense access, and modular expansion in a 1U rack-mountable form factor.
Included Configuration of Huawei MA5608T
| Component | Specification |
|---|---|
| Chassis Model | Huawei MA5608T (Branded, Factory Original) |
| Main Control Board | 1 × MCUD (GE-based control board) |
| Uplink Interface | 2 × GE ports (via MCUD) |
| Service Slots | 2 × Service board slots (GPON/Combo PON/XG-PON) |
| Power Supply Slot | Supports dual DC (-48V) modules (not included) |
| Mounting Style | 19″ rack-mountable (1U height) |
| Status | Brand New, Huawei Original, Unused |
MCUD Main Control Board Specs
| Feature | Details |
|---|---|
| Control Functions | System management, routing, switching, QoS |
| Uplink Ports | 2 × GE (Electrical or Optical Combo) |
| Backplane Switching | Connects service boards via high-speed bus |
| Protocol Support | Layer 2/3 forwarding, IGMP, PPPoE, DHCP, VLAN |
| Management Support | CLI, SNMP, Web GUI, Telnet, OMCI |
| Redundancy | Supports dual MCUD or SCUN boards (optional) |
Huawei MA5608T Chassis Specifications
| Parameter | Value |
|---|---|
| Dimensions | 442mm × 220mm × 43.6mm (Standard 1U) |
| Weight | Approx. 3.5–4 kg (with 1 control board) |
| Service Slots | 2 (for GPON, XG-PON, or Combo PON cards) |
| Control Board Slot | 1 (MCUD or SRU/SCUN) |
| Power Supply | Dual DC -48V input (modules sold separately) |
| Temperature Range | -40°C to +65°C |
| Compliance | CE, RoHS, ITU-T G.984/G.988, ISO9001 |
Huawei MA5608T Applications
-
🏘️ Fiber to the Home (FTTH) Deployments
-
🏢 MDUs and Small ISPs Network Core
-
📡 GPON Aggregation and Access Networks
-
☁️ Triple-Play Services – VoIP, Internet, IPTV
-
🌐 Carrier-Grade Metro Edge Access
Customization & Expansion Options
This chassis is modular and expandable based on network needs:
-
🔧 Add-On Service Boards: 8-port, 16-port, or 32-port GPON, Combo PON
-
🔧 Upgrade Control: Swap MCUD for SCUN/SRU (higher throughput & redundancy)
-
🔧 Power Options: Add dual DC power modules for redundancy
-
🔧 Uplink Expansion: Add 10GE uplink via upgraded control board
-
🔧 ONUs Compatibility: Works with EG8145V5, HG8010H, HG8546M, etc.
📦 Tech Specs – OLT Chassis Configuration (H801MCUD | No GPON Ports)
⚙️ Configuration
| Component | Specification |
|---|---|
| Main Control Board | H801MCUD: 1 |
| Upstream Ports | GE SFP: 4 |
| GPON Ports | 0 |
| Service Slots Remaining | 2 |
| Power Supply Mode | DC power supply: -48 V DC |
📐 Device Specifications
| Attribute | Details |
|---|---|
| Dimensions (W × D × H) | 482.6mm × 244.5mm × 88.1mm (IEC cabinet compatible) |
| Weight (Empty Chassis) | 7.5 kg |
Wholesale & Project Supply
Ideal for ISPs, system integrators, FTTH contractors, and network distributors:
-
📦 OEM Branding & Custom Labeling Available
-
📦 MOQ Flexibility & Bulk Discounts
-
📦 Test Reports & Compliance Certificates Provided
-
📦 Kitting Available: ONUs, splitters, patch cords, and adapters
-
📦 Fast Global Delivery with Pre-Sale Support
Why Choose the Huawei MA5608T with MCUD?
-
✔️ Compact Design – Perfect for space-limited racks
-
✔️ Cost-Efficient GPON Launch Platform
-
✔️ Field-Proven Reliability with Carrier-Grade Hardware
-
✔️ Fully Modular for Future Growth & Service Additions
-
✔️ Huawei Original – Trusted by Operators Worldwide
Order Now
Start your GPON deployment with the Huawei MA5608T Chassis + MCUD GE Main Control Board. A powerful and flexible OLT base unit that scales with your network.
