- Model Number:ZTE ZXHN F601
- Type:ONU
- Place of Origin:Guangzhou
- Brand Name:Huawei
- Use:FTTH
- Warranty Time:1 year
- Network:Wired LAN, wifi
- Supply Ability5000 Piece/Pieces per Week
- Packaging Detailscartons
- PortShenzhen
- Lead time:Quantity(pieces)1 – 10000>10000Lead time (days)15To be negotiated
Overview
ZTE F601 FTTH is a GPON Optical Network Terminal designed for FTTH. It provides high-performance forwarding capabilities to ensure excellent experience with Internet and HD video services. It has a small, smart appearance and green, energy-saving advantage. ZTE GPON ONT Series of ONTs for FTTX deployment scenarios cover various user interfaces: FE, GE, POTS, RF, Wi-Fi, USB and suitable for digital home networks. They are supporting the latest Wi-Fi 802.11n technology for higher bandwidth access. Easy OAM saves OPEX – support TR069, zero-touch and batch configuration. All EDGE Technologies provided ZTE GPON ONT has Multiple certifications – CE, FCC, RoHS, CoC, Wi-Fi.
Specifications
| Brand | ZTE |
| Model | F601 |
| Optical port | 1 x GPON interface (SC/PC or SC/APC) |
| Transmit rate | 2.488Gbps downstream; 1.244Gbps upstream |
| User-Network Interface | 1 x10/100/1000Base-T |
| Wavelength | Receiving: 1480~1500 nm Transmitting: 1290~1330 nm |
| Receiving Sensitivity | -28dBm |
| Transmitting Optical Power | 0.5~5dBm |
| Power consumption | <6W |
| Dimensions | 110mm(W) x 90mm(H) x 53mm(D) |
| Working temperature: | 0oC ~ 40oC |
| Working humidity | 5% ~ 95% |
| Weight | 190g |
| Power supply | 12V DC |
Features
- Supported service: Internet, IPTV
- GPON: 8 T-CONTs, 32 GEM Ports
- VLAN: 802.1Q, 802.1P, 802.1ad
- MAC address table: 256
- Multicast: IGMP v1/v2 Snooping
- Multicast group per user port: 256
- QoS: service flow classification based on physical port, Ethernet type; ingress rate limit; egress shaping
- Management: local web management, OMCI
