- Products Status:Stock
- Ports:16
- Transmission Rate:10/100Mbps
- Function:POE, QoS, VLAN Support
- Communication Mode:Full-Duplex & Half-Duplex
- Switch Capacity:20G
- Model Number:TS6216P-2G1F
- Place of Origin:Guangdong, China
- PoE Standard:IEEE802.3af /IEEE802.3at
- PoE power:52VDC 2.3A
- Product Name:16 Port PoE Switch
- PoE Ports:1-16 Port Support PoE
- Uplink Ports:2*1000Mbps Uplink Ports, 1*1000mbps SFP
- Applications:Support PoE IP Cameras
- Warranty:1 Year
- Keywords:16 port PoE switch
- Certification:CE FCC
-
- Packaging Details
carton
-
- Port
Guangzhou
- Picture Example:
- Lead time:Quantity(pieces)1 – 23 – 100101 – 500>500Lead time (days)51520To be negotiated
Product Description
16-Port 10/100Mbps POE Switch Bulit-in 300W Long Distance 250m Ethernet Switch
Application:
* Wireless Access Point
* IP Camera
* IP Phone
* Computer Networks
* IP Camera
* IP Phone
* Computer Networks
|
Model
|
16FE(poe)+2G+1F port 250m POE switch(Built-in)
|
|
Model No.
|
TS6216P-2G1F
|
|
PoE Port
|
1 to 16 port support IEEE802.3af/at
|
|
UP link port
|
17th-18th port support 1000Mbps
|
|
SFP port
|
19th port support 1000Mbps
|
|
PoE output
|
15.4W/30W IEEE802.3af/at
|
|
PoE whole power
|
300W
|
|
PoE type
|
End-span
|
|
Power distance
|
≤250m
|
|
Network Standard
|
IEEE 802.3、 IEEE802.3u、802.3x、802.3af/at
|
|
Network Medium
|
100/1000BASE-TX: 5 class and above non shielded twisted pair
|
|
Data Distance
|
≤250m
|
|
Switch capability
|
20Gbps
|
|
Forwarding Mode
|
Store and forward
|
|
Forwarding Rate
|
100Mbps:14880pps 1000Mbps:14800pps 1000BASE-T: 1488095pps/port
|
|
MAC Address
|
2K MAC address table
|
|
Port function
|
Power priority mechanism, fast and forward, MAC automatic learning and aging
IEEE802.3X Full-duplex and mode and backpressure for Half-duplex mode |
|
Indicator
|
LINK/ACT. 100Mbps;POE Status indicator; POWER indicator;EXTENDER indicator
|
|
Working Environment
|
Working Temperature: 0°– 55°C
|
|
Input power
|
AC100-240V 50/60HZ
|
|
Weight
|
3.0kg
|
|
Size
|
295mm*195mm*45mm(L*W*H)
|
